Product Description Three layers concrete shuttering panels are high-quality, 3-ply wooden panels, made of spruce or pine wood acquired from sustainable forests. The panels are fully coated with a highly resistant melamine resin, giving them excellent protection. They are mostly used for concrete Formwork
, but can also be used for other purposes due to their exceptional functionality. They are distinguished for their superior quality, durability and multiple uses. 3 Ply Yellow Melamine panels offer a timber grain transfer onto the concrete soffit and do offer smoother finishes as they are used.Product Overviews
,Major advantage·Durable and weather resistant overlay ·Large size with unvisible joints ·Strong and rigid ·Easy to clean and re-use ·Good chemical resistance ·Dimensionally stable ·Easy to machine and fasten using coventional ·Woodworking impacts and other forms of bruising ·Environmentlly friendly ·Weather and boil proof bonding Product gurantee:.Dimensionaly stable throgh a techical lay-up.Almost no crack occurance.Hign bending strenght and sittness.sanded surface of perfect results .A higher muber of houses.High endurance due to gluing all around Panel Size 970/1000/1970//2000/2500/3000x500mm also can according to customer request The first measurement indicates orientation of the surface veneer grain. other size are available on request FORMWORK PANELS(21) Thickness: 21mmWidth: 500mmLenghts: 970/1,000/1,970/2,000/2,500/3,000mm FORMWORK PANELS(18) Thickness: 18mmWidth: 500mmLenghts: 970/1,000/1,970/2,000/2,500/3,000mm FORMWORK PANELS(27) Thickness: 27mmWidth: 500mmLenghts: 970/1,000/1,970/2,000/2,500/3,000mm Specifcation SIZE TOLERANCES Measured in accordance with standard EN 324, the plywood size and squareness tolerances meet EN 315 requirements.
BONDING CLASSES 3-p
Panels are boned with a weather and boil-resistantphenolic formaldehyde adhesive (WBP,BFU,AW ,exterior) . The gluing meets the requirements of the following international standards: EN314-2/Class 3(exterior)DIN 68705-3/BFU 100BS 6566 Part 8/WBPPS1-07G/TBT/N/ISR/569 PACKING 3p panels are packed in moisture resistant plastic wrapping
Number of panels per pallet for 40HC container by
Panel size (mm)
MOISTURE CONTENT15%+/-3% at time of delivery MASS IN KG/m218mm thickness:8.3 KG/m221mm thickness:9.7KG/m227mm thickness:12.5 KG/m2 DENSITY Approximately 450-465 kg/m3SURFACEQuality selection Standard quality Surface sanded Treated with durable melamine resin seatant DIMENSIONAL TOLERANCES In accordance to EN 13353 Length,width: limit deviations +/-2mm Panel thickness: 0.5mm within a panel limit deviations +/-1 mm Edge straightness: 1.0mm/mPerpendicularity: 1.0mm/m Application
Certifications CARB: Certificate No.FWI-120CARB of the United States authenticated in 2015We produce according to the strictest QMS FSC:Certificate No. TUVDC-COC-888030/TUVDC-COC-888031FSC authenticated in May 2014No randomly, deforestation, we care about natural resources. Waterproof:Have a good waterproof performance,Compliance with EN314, DIN 68704-3/BFU 100.BS 6566 Part 8 / WBP standard Unique load capacity:Panel strength properties strong Exceptional durability : Number of use 20-50 times, CE:certificate No.1301-CPD-0569CE certification authenticated in 2011Our products have passed conformity assessment procedures process. ISO 14001Qinge passed ISO14001 Environmental Management system in 2008 Saving natural resources, promoting sustainable development. ISO9001:Cerificate No.11716Q10374R2SQinge passed ISO9001 Environment management system in June 2010.Perfect Quality assurance system. Product testing results : certificate No.14-816Products tested in 2006 Quality Guaranteed. Factory and Production
Packing and shipping
Our team and exhibition
Our customer and Our team
Contact us if you need more details on Concrete Shuttering Panel. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Three Ply Shuttering Panels、Three Ply Yellow Shuttering Boards. If these products fail to match your need, please contact us and we would like to provide relevant information.
